100-125mm Bluetooth IP67 Three Point Digital Bore Micrometer - XTDM-BT Series (Bowers)
100-125mm Bluetooth IP67 Three Point Digital Bore Micrometer - XTDM-BT Series (Bowers)
Related Products
| Image | Code | Stock | Price (Ex VATInc. VAT) |
|---|
Product Information
Features & Benefits
- Ergonomic design with larger and clearer LCD display.
- IP67 protection.
- 0.001mm resolution.
- UKAS certificates supplied as standard with all setting rings and micrometers.
- Proximity output with built-in Bluetooth.
- Bore gauges manufactured according to DIN 863, part 4.
- 2-6mm 2 point measurement / 6-300mm 3 point measurement.
- Supplied in fitted wooden case.
- Bi-directional communication.
- Tungsten carbide measuring faces on all 3-point heads from 12.5mm.
- Extensions available above 6mm for deep hole measurement.
- Ratchet stop to ensure consistent measurement.
Specification
| Category | Measuring |
|---|---|
| Sub Category | Bore Gauges & Internal Micrometers |
| Sub Category 2 | 3 Point Bore Micrometers |
| Range (mm) | 100-125 |
| Flutes | 3 |
| Range (inch) | 3-4" |
| Measuring Force | 5-10N |
| Setting Ring | 125mm |
| Extension Rod | 150mm |
| l | 107 |
| Pcs | 6 |
| Includes | 50-63mm, 62-75mm |
| Depth | 115mm |
| Tip Angle | 30° |
| Travel Heads | 13mm |
| b | 15.5 |
| c | 107 |
| Accuracy | 0.006mm |
| Graduation | .001" |
| Resolution | 0.001mm/0.00005" |
| Read Out | Digital |
| IP Rating | IP67 |
| Individual Or Set | Individual |
| Data Output | Yes |
| Brand | Bowers |
