Performance HSS Drills

Performance HSS Drills

Range of high performance HSS drills for a wide range of materials. These drills have improved tool life and performance over general purpose HSS drills.

Filter By arrow
carrat-down

4 Items

Sort By
carrat-down
sort-descending
HPD-SUS TiN Coated HSS Vanadium Stub Drill - DJ543 (YG-1)
HPD-SUS TiN Coated HSS Vanadium Stub Drill - DJ543 (YG-1)

The DJ543 series HPD-SUS stub drills have a vanadium cobalt substrate that gives exceptional wear resistance on stainless steel. These are perfect when through coolant is not available. Diameters rang...

  • The ideal drill for machining stainless steel where through coolant is not available
  • Vanadium Cobalt substrate gives exceptional wear resistance on stainless steel
  • 4 facet flute design and web thinning prevents work hardening
  • Deep flute pockets prevent chip clogging and built up edge
  • Also suitable for drilling soft steels, aluminium and other long chipping materials

Size

Diameter (mm)2 - 13
Overall Length (mm)44 - 108
Flute Length (mm)12 - 51
Shank (mm)2 - 13

From £5.53 £4.61

View Products
HPD-SUS TiN Coated HSS Vanadium Jobber Drill - DJ544 (YG-1)
HPD-SUS TiN Coated HSS Vanadium Jobber Drill - DJ544 (YG-1)

The DJ544 series HPD-SUS jobber drills have a vanadium cobalt substrate that gives exceptional wear resistance on stainless steel. These are perfect when through coolant is not available. Diameters ra...

  • The ideal drill for machining stainless steel where through coolant is not available
  • Vanadium Cobalt substrate gives exceptional wear resistance on stainless steel
  • 4 facet flute design and web thinning prevents work hardening
  • Deep flute pockets prevent chip clogging and built up edge
  • Also suitable for drilling soft steels, aluminium and other long chipping materials

Size

Diameter (mm)2 - 20
Overall Length (mm)56 - 191
Flute Length (mm)24 - 125
Shank (mm)2 - 20

From £6.26 £5.22

View Products
HPD TiN Coated Premium HSS Self Centering Stub Drill - D4541 (YG-1)
HPD TiN Coated Premium HSS Self Centering Stub Drill - D4541 (YG-1)

The D4541 series HPD stub drills have a premium HSS substrate which provides higher feed rates and tool life than standard cobalt drills. They have a reinforced web for high rigidity and good surface ...

  • High performance drill designed for machining carbon steel, alloyed steel & tool steel.
  • Also suitable for cast iron and aluminium drilling
  • Premium HSS substrate for higher feed rates and tool life than standard cobalt drills
  • Reinforced web for high rigidity and good surface finish
  • Self centering

Size

Diameter (mm)2 - 13
Overall Length (mm)44 - 108
Flute Length (mm)12 - 51
Shank (mm)2 - 13

From £5.78 £4.82

View Products
HPD TiN Coated Premium HSS Self Centering Jobber Drill - D4542 (YG-1)
HPD TiN Coated Premium HSS Self Centering Jobber Drill - D4542 (YG-1)

The D4542 series HPD jobber drills have a premium HSS substrate which provides higher feed rates and tool life than standard cobalt drills. They have a reinforced web for high rigidity and good surfac...

  • High performance drill designed for machining carbon steel, alloyed steel & tool steel.
  • Also suitable for cast iron and aluminium drilling
  • Premium HSS substrate for higher feed rates and tool life than standard cobalt drills
  • Reinforced web for high rigidity and good surface finish
  • Self centering

Size

Diameter (mm)2 - 32
Overall Length (mm)56 - 245
Flute Length (mm)24 - 160
Shank (mm)2 - 32

From £6.59 £5.49

View Products
