Gerardi Standard Series Vice Jaw Plates & Parallels

• Hydro-Pneumatic clamping: vice jaw actuation is controlled by a power unit with pneumatic control and single effect cylinder.
• 2-4 vices can be operated simultaneously.
• Compatible with Gerardi Standard Series Vices.
• Supplied with 1 operating switch.
• Jaw actuation controlled by hand switch as standard.
• Also available with solenoid valve electromagnetics for CNC contolled operation.
• Consistent clamping forces which can be pre-set.
• Up to 4 movable jaws can be operated with 1 power unit.
• Contact the Cutwel technical team for help and advice on the best solution to improve your productivity.

• Soft Jaw (Quick Change)

COMPATIBLE WITH THE FOLLOWING GERARDI VICES:

ART1A, ART1AZ, ART20A, ART30A. For further technical advice or to check compatibility please contact our technical team today.

• Hydro-Pneumatic clamping: vice jaw actuation is controlled by a power unit with pneumatic control and single effect cylinder.
• 1-4 vices can be operated independently.
• Compatible with Gerardi Standard Series Vices.
• Supplied with 1 operating switch per cylinder/jaw.
• Jaw actuation controlled by hand switch as standard.
• Also available with solenoid valve electromagnetics for CNC contolled operation.
• Consistent clamping forces which can be pre-set.
• Up to 4 movable jaws can be operated with 1 power unit.
• Contact the Cutwel technical team for help and advice on the best solution to improve your productivity.

The jaws feature an innovative comb system allowing them to be positioned or removed from the vice in a couple of seconds.   ART230E jaws are hardened to 60 Rockwell and all working surfaces ground within 0.01mm. All Standard Flex jaw plates are supplied in singles.

• Step Jaw (Quick Change)

COMPATIBLE WITH THE FOLLOWING GERARDI VICES:

ART1A, ART1AZ, ART20A, ART30A. For further technical advice or to check compatibility please contact our technical team today.

The jaws feature an innovative comb system allowing them to be positioned or removed from the vice in a couple of seconds.   ART230F jaws are hardened to 60 Rockwell and all working surfaces ground within 0.01mm. All Standard Flex jaw plates are supplied in singles.

• Prismatic Jaw (Quick Change)

COMPATIBLE WITH THE FOLLOWING GERARDI VICES:

ART1A, ART1AZ, ART20A, ART30A. For further technical advice or to check compatibility please contact our technical team today.

The jaws feature an innovative comb system allowing them to be positioned or removed from the vice in a couple of seconds.   ART230G jaws are hardened to 60 Rockwell and all working surfaces ground within 0.01mm. All Standard Flex jaw plates are supplied in singles.

• Stop Jaw (Quick Change)

COMPATIBLE WITH THE FOLLOWING GERARDI VICES:

ART1A, ART1AZ, ART20A, ART30A. For further technical advice or to check compatibility please contact our technical team today.

The jaws feature an innovative comb system allowing them to be positioned or removed from the vice in a couple of seconds.   ART230D jaws are hardened to 60 Rockwell and all working surfaces ground within 0.01mm. All Standard Flex jaw plates are supplied in singles.

• Serrated Jaw (Quick Change)

COMPATIBLE WITH THE FOLLOWING GERARDI VICES:

ART1A, ART1AZ, ART20A, ART30A. For further technical advice or to check compatibility please contact our technical team today.

The jaws feature an innovative comb system allowing them to be positioned or removed from the vice in a couple of seconds.   ART230C jaws are hardened to 60 Rockwell and all working surfaces ground within 0.01mm. All Standard Flex jaw plates are supplied in singles.

• Hard Smooth Jaw (Quick Change)

COMPATIBLE WITH THE FOLLOWING GERARDI VICES:

ART1A, ART1AZ, ART20A, ART30A. For further technical advice or to check compatibility please contact our technical team today.

The jaws feature an innovative comb system allowing them to be positioned or removed from the vice in a couple of seconds.   ART230M jaws are hardened to 60 Rockwell and all working surfaces ground within 0.01mm. All Standard Flex jaw plates are supplied in singles.

• Angle Jaw (Quick Change)

COMPATIBLE WITH THE FOLLOWING GERARDI VICES:

ART1A, ART1AZ, ART20A, ART30A. For further technical advice or to check compatibility please contact our technical team today.

ART243 jaws are hardened to 60 Rockwell and all working surfaces ground within 0.01mm. All Standard Series jaw plates are supplied in singles.

• Grooved Narrow Width Jaw (Straight Plate)
• Jaw width: 74mm / 3"
• Vice Size 1 (3")

COMPATIBLE WITH THE FOLLOWING GERARDI VICES:

ART15, ART25, ART35. For further technical advice or to check compatibility please contact our technical team today.

ART243S jaws are hardened to 60 Rockwell and all working surfaces ground within 0.01mm. All Standard Series jaw plates are supplied in singles.

• Serrated Narrow Width Jaw (Straight Plate)

COMPATIBLE WITH THE FOLLOWING GERARDI VICES:

ART15, ART25, ART35. For further technical advice or to check compatibility please contact our technical team today.

ART245 jaws are hardened to 60 Rockwell and all working surfaces ground within 0.01mm. All Standard Series jaw plates are supplied in singles.

• Smooth Narrow Width Jaw (Straight Plate)

COMPATIBLE WITH THE FOLLOWING GERARDI VICES:

ART15, ART25, ART35. For further technical advice or to check compatibility please contact our technical team today.

Prismatic Intermediate Step Jaw

COMPATIBLE WITH THE FOLLOWING GERARDI VICES:

ART1, ART1Z, ART21, ART30, ART14, ART24, ART34, ART1A, ART1AZ, ART20A, ART30A. For further technical advice or to check compatibility please contact our technical team today.

Like all Gerardi vices, it is made from heat treated hardened steel and all working surfaces are precision ground. To check compatibility with your vice contact our technical team today.

The innovative grip jaw plate features grip inserts which can be interchanged for different materials, offering exceptional grip to prevent workpieces moving when positioned on the parallel.

ART246G jaws are hardened to 60 Rockwell and all working surfaces ground within 0.01mm. All Standard Series jaw plates are supplied in singles.

• Grip Jaw (Straight Plate)

COMPATIBLE WITH THE FOLLOWING GERARDI VICES:

ART14, ART24, ART34. For further technical advice or to check compatibility please contact our technical team today.

ART242 jaws are hardened to 60 Rockwell and all working surfaces ground within 0.01mm. All Standard Series jaw plates are supplied in singles.

• Grooved Jaw (Straight Plate)

COMPATIBLE WITH THE FOLLOWING GERARDI VICES:

ART14, ART24, ART34. For further technical advice or to check compatibility please contact our technical team today.

ART242S jaws are hardened to 60 Rockwell and all working surfaces ground within 0.01mm. All Standard Series jaw plates are supplied in singles.

• Serrated Jaw (Straight Plate)

COMPATIBLE WITH THE FOLLOWING GERARDI VICES:

ART14, ART24, ART34. For further technical advice or to check compatibility please contact our technical team today.

ART244 jaws are hardened to 60 Rockwell and all working surfaces ground within 0.01mm. All Standard Series jaw plates are supplied in singles.

• Smooth Jaw (Straight Plate)

COMPATIBLE WITH THE FOLLOWING GERARDI VICES:

ART14, ART24, ART34. For further technical advice or to check compatibility please contact our technical team today.

• Soft Jaw Narrow Width (Straight Plate)

COMPATIBLE WITH THE FOLLOWING GERARDI VICES:

ART15, ART25, ART35. For further technical advice or to check compatibility please contact our technical team today.

The parallels are magnetised on one side (to prevent chips sticking to them) and position perfectly on Gerardi Standard Series vices, offering accuracy within 20 microns. They can be positioned in seconds and offer superior accuracy and repeatability to using standard ground parallels.

ART313R magnetic parallels are supplied in pairs and are available in a range of heights, suitable for narrow width jaw vices.

• Magnetic Parallel Narrow Width

COMPATIBLE WITH THE FOLLOWING GERARDI VICES:

ART15, ART25, ART35. For further technical advice or to check compatibility please contact our technical team today.

The plates are magnetised on one side (to prevent chips sticking to them) and position perfectly on Gerardi Standard Series vices, offering accuracy within 20 microns. They can be positioned in seconds and offer superior accuracy and repeatability to using standard ground angle blocks.

ART314 magnetic angle plates are supplied in pairs and are available in a range of angles.   They are suitable for use with all Standard Series or Standard Flex vices.

• Magnetic Angle Parallel

COMPATIBLE WITH THE FOLLOWING GERARDI VICES:

ART14, ART24, ART34, ART1, ART1Z, ART21, ART30. For further technical advice or to check compatibility please contact our technical team today.

ART217 jaws are hardened to 60 Rockwell and all working surfaces ground within 0.01mm.

• Prismatic Solid Step Jaw

COMPATIBLE WITH THE FOLLOWING GERARDI VICES:

ART1, ART1Z, ART21 ART30, ART14, ART24, ART34. For further technical advice or to check compatibility please contact our technical team today.

• Soft Jaw (Pull Down)

COMPATIBLE WITH THE FOLLOWING GERARDI VICES:

ART1, ART1Z, ART21 ART30. For further technical advice or to check compatibility please contact our technical team today.

• Magnetic parallel plates
• Available in size 1
• For Gerardi Standard Series Vice

• For more information please call our tech team on 01924 869 614
