A32S-DWLNL-08 32mm Steel Shank Boring Bar, Left Hand, Through Coolant, for WNMG08 Inserts, 95° Approach, Double Clamp (Korloy)
A32S-DWLNL-08 32mm Steel Shank Boring Bar, Left Hand, Through Coolant, for WNMG08 Inserts, 95° Approach, Double Clamp (Korloy)
| Overall Length (mm) | 250 |
|---|---|
| Shank (mm) | 32 |
Related Products
| Image | Code | Stock | Price (Ex VATInc. VAT) |
|---|
Product Information
Features & Benefits
- Through coolant boring bar prolongs tool life by directing coolant right to the cutting edge whilst also assisting with swarf evacuation
- Suitable for use with WNMG style turning inserts (also suitable for WNMA, WNMM, WNGA, WNGG etc)
- Excellent value through coolant steel shank boring bar with 95 degree approach angle
- Ultra powerful double clamp style clamping system - high precision clamping system for longer tool life and excellent surface finish
- For the best performance it is recommended to clamp on a 1/3 of the bar's length, as a minimum.
- Made by Teknik, offering excellent value and cost efficiency
Specification
| Category | Lathe Tools |
|---|---|
| Sub Category | Boring Bars |
| Sub Category 2 | Through Coolant Steel Shank Boring Bars |
| Shank (mm) | 32 |
| Overall Length (mm) | 250 |
| Reach (mm) | 50 |
| Inserts | WN**08 |
| ISO Code | A32S-DWLNL-08 |
| Min Bore | 40 |
| Hand | Left |
| Alternative Part Number | A32S-DWLNL-08 |
| Shim | SW42V |
| Shim Screw | FTKA0410 |
| Clamp Screw | CHX0518 |
| Clamp | CVH4 |
| Insert Series | WNMG |
| Through Coolant | Yes |
| Angle | 95° |
| Holder Material | Steel |
| Holder Style | DWLNR/L |
| Clamp Type | Double Clamp |
| Brand | Korloy |
Application
