Vernier Height Gauge with Fine Adjustment - 1250 Series (Insize)

The Insize 1250 Vernier Height Gauge is made from stainless steel with a chrome finish for longer tool life and durability from machine shop wear. Available with fine adjustment for precise measuremen...

Range up to 1000mm/40".
Graduation 0.02mm/0.001".
Carbide tipped scriber.
Fine adjustment.
Made of stainless steel (except base).
Satin chrome plated scale.
Supplied with magnifier.
Supplied with dust cover.
Optional accessory: dial test indicator holder (code 6293-6), clamp for protractors (code 2372-clamp).

View Products

Vernier Height Gauge - 1253 Series (Insize)

The Insize 1253 Vernier Height Gauge is made from stainless steel with a chrome finish for longer tool life and durability from machine shop wear. Available with fine adjustment for precise measuremen...

Range up to 250mm/10".
Graduation 0.02mm/0.001".
Carbide tipped scriber.
Fine adjustment.
Made of stainless steel (except base).
Satin chrome plated scale.
Optional accessory: dial test indicator holder (code 7151-CL1).

View Products

Vernier Adjustable Scale Height Gauge - 506/514 Series (Mitutoyo)

This vernier height gauge fits comfortably in the hand and moves easily on the surface plate. The main scale slides and clamps within the column for quick and convenient zero-setting. Mitutoyo are a m...

Range: up to 0-1000mm / 0-40".
Resolution: up to ±0.03mm.
Scale adjustment: up to 25 mm (1").
Made by Mitutoyo - Market leader in the engineering measuring tool sector.
Fits comfortably in the hand and moves easily on the surface plate.
The main scale slides and clamps within the column for quick and convenient zero-setting.
Large locking screws are used both for the slider and fine adjustment clamps to make clamping easy and secure.
Operability of slider has been improved.
Large mainscale engraving for fatigue-free working.
Carbide-tipped scriber (900173 for 506-208, 07GZA000 for 514-103/5/7, 905200 for 514-109) is provided as a standard accessory. (Scriber clamp 07GZA004 for 506-208 05GZA033 for 514-103/5/7/9.)

From £341.92 £284.93

View Products

Linear Height Digimatic 2D Measurement System - 518 Series (Mitutoyo)

This digital height gauge has an excellent accuracy of (1.1+0.6L/600) μm with 0.1 μm / 0.4 μm resolution/repeatability. An excellent large colour LCD screen with excellent visibility is used and a ...

Range: 0-972mm.
Resolution (switchable): 0.0001 / 0.001 / 0.01 / 0.1 mm or .000001 / .00001 / .0001 / .001".
Made by Mitutoyo - Market leader in the engineering measuring tool sector.
Excellent accuracy of (1.1+0.6L/600) μm with 0.1 μm / 0.4 μm resolution/repeatability.
High-accuracy Height Gauge incorporating a wide range of measurement functions.
To achieve best-in-class accuracy, a high-accuracy reflective-type linear encoder and an exceptionally straight guide are used.
Measurement can be implemented by icon-based commands that also support easy one-key operation. Perpendicularity (frontal) of 5 μm and straightness of 4 μm are guaranteed.
A best-in-class large colour LCD with excellent visibility is used.
Pneumatic full/semi-floating suspension system allows adjustment of air-cushion height.
Basic statistical functions are provided and additionally, RS-232C data output provides the option of evaluating measurement data externally with SPC software on a PC.

View Products
