| Image | Code | Stock | Price (Ex VATInc. VAT) |
|---|
|
Diameter (mm)
|
Shank (mm)
|
Radius
|
Flute Length (mm)
|
Overall Length (mm)
|
Reach (mm)
|
Flutes
|
Chamfer Prep (mm)
|
Neck Diameter (mm)
|
||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Diameter (mm): 4 | Shank (mm): 6 | Radius: | Flute Length (mm): 16 | Overall Length (mm): 60 | Reach (mm): | Flutes: 8 | Chamfer Prep (mm): | Neck Diameter (mm): |
green
Available for
Delivery within 7-10 Days *
|
£164.64
£137.20
|
|
|
| Diameter (mm): 5 | Shank (mm): 6 | Radius: | Flute Length (mm): 18 | Overall Length (mm): 60 | Reach (mm): | Flutes: 8 | Chamfer Prep (mm): | Neck Diameter (mm): |
green
Available for
Delivery within 7-10 Days *
|
£168.24
£140.20
|
|
|
| Diameter (mm): 6 | Shank (mm): 6 | Radius: | Flute Length (mm): 20 | Overall Length (mm): 60 | Reach (mm): | Flutes: 8 | Chamfer Prep (mm): | Neck Diameter (mm): |
green
Available for
Delivery within 7-10 Days *
|
£173.03
£144.19
|
|
|
| Diameter (mm): 6 | Shank (mm): 6 | Radius: | Flute Length (mm): 25 | Overall Length (mm): 65 | Reach (mm): | Flutes: 8 | Chamfer Prep (mm): | Neck Diameter (mm): |
green
Available for
Delivery within 7-10 Days *
|
£181.33
£151.11
|
|
|
| Diameter (mm): 6 | Shank (mm): 6 | Radius: | Flute Length (mm): 30 | Overall Length (mm): 75 | Reach (mm): | Flutes: 8 | Chamfer Prep (mm): | Neck Diameter (mm): |
green
Available for
Delivery within 7-10 Days *
|
£187.30
£156.08
|
|
|
| Diameter (mm): 6 | Shank (mm): 6 | Radius: | Flute Length (mm): 50 | Overall Length (mm): 100 | Reach (mm): | Flutes: 8 | Chamfer Prep (mm): | Neck Diameter (mm): |
green
Available for
Delivery within 7-10 Days *
|
£207.60
£173.00
|
|
|
| Diameter (mm): | Shank (mm): | Radius: 0.3 | Flute Length (mm): | Overall Length (mm): | Reach (mm): 68 | Flutes: 8 | Chamfer Prep (mm): 0.74 | Neck Diameter (mm): 7.5 |
green
Available for
Delivery within 7-10 Days *
|
£205.20
£171.00
|
|
|
| Diameter (mm): 8 | Shank (mm): 8 | Radius: | Flute Length (mm): 32 | Overall Length (mm): 75 | Reach (mm): | Flutes: 8 | Chamfer Prep (mm): | Neck Diameter (mm): |
green
Available for
Delivery within 7-10 Days *
|
£226.69
£188.91
|
|
|
| Diameter (mm): 8 | Shank (mm): 8 | Radius: | Flute Length (mm): 50 | Overall Length (mm): 100 | Reach (mm): | Flutes: 8 | Chamfer Prep (mm): | Neck Diameter (mm): |
green
Available for
Delivery within 7-10 Days *
|
£250.54
£208.78
|
|
|
| Diameter (mm): 10 | Shank (mm): 10 | Radius: | Flute Length (mm): 32 | Overall Length (mm): 72 | Reach (mm): | Flutes: 8 | Chamfer Prep (mm): | Neck Diameter (mm): |
green
In Stock for
Next Day Delivery *
|
£291.11
£242.59
|
|
|
| Diameter (mm): 10 | Shank (mm): 10 | Radius: | Flute Length (mm): 60 | Overall Length (mm): 120 | Reach (mm): | Flutes: 8 | Chamfer Prep (mm): | Neck Diameter (mm): |
green
Available for
Delivery within 7-10 Days *
|
£325.75
£271.46
|
|
|
| Diameter (mm): 12 | Shank (mm): 12 | Radius: | Flute Length (mm): 32 | Overall Length (mm): 82 | Reach (mm): | Flutes: 8 | Chamfer Prep (mm): | Neck Diameter (mm): |
green
Available for
Delivery within 7-10 Days *
|
£316.16
£263.47
|
|
|
| Diameter (mm): 12 | Shank (mm): 12 | Radius: | Flute Length (mm): 70 | Overall Length (mm): 120 | Reach (mm): | Flutes: 8 | Chamfer Prep (mm): | Neck Diameter (mm): |
green
Available for
Delivery within 7-10 Days *
|
£399.68
£333.07
|
|
|
| Diameter (mm): 16 | Shank (mm): 16 | Radius: | Flute Length (mm): 36 | Overall Length (mm): 92 | Reach (mm): | Flutes: 8 | Chamfer Prep (mm): | Neck Diameter (mm): |
green
Available for
Delivery within 7-10 Days *
|
£386.94
£322.45
|
|
|
| Diameter (mm): 16 | Shank (mm): 16 | Radius: | Flute Length (mm): 80 | Overall Length (mm): 150 | Reach (mm): | Flutes: 8 | Chamfer Prep (mm): | Neck Diameter (mm): |
green
Available for
Delivery within 7-10 Days *
|
£523.85
£436.54
|
|
|
| Diameter (mm): 20 | Shank (mm): 20 | Radius: | Flute Length (mm): 45 | Overall Length (mm): 104 | Reach (mm): | Flutes: 8 | Chamfer Prep (mm): | Neck Diameter (mm): |
green
Available for
Delivery within 7-10 Days *
|
£497.78
£414.82
|
|
*Geographical & product exclusions apply for next day delivery (calculated on checkout). Any other lead times shown are estimated and subject to availability.
| Category | Milling |
|---|---|
| Sub Category | Milling Cutters |
| Sub Category 2 | PCD, CVD & Diamond Coated Milling Cutters |
| Substrate | Carbide |
| Surface Treatment | Coated (Diamond) |
| End Profile | Square |
| Flute Type | Standard |
| Shank Type | Plain |
| Applicable Materials | Non-Ferrous |
| Helix Profile | Standard |
| Performance | 5 |
| Coating Description | Diamond Coated |
| Substrate Description | Micrograin Carbide |
| Helix Angle | 8° |
| Type | Straight Cut |
| Brand | Karnasch |
