4 Flute V7 Plus Coated Carbide Reduced Neck Multiple Helix Corner Radius Weldon Shank End Mill - GMF63 (YG-1)
GMF63 series CORNER RADIUS end mills are available from 3-20mm diameter with a Weldon shank. The neck of the...
Read more
View Products
Related Products
| Image | Code | Stock | Price (Ex VATInc. VAT) |
|---|
|
Diameter (mm)
|
Shank (mm)
|
Radius
|
Flute Length (mm)
|
Overall Length (mm)
|
Reach (mm)
|
Flutes
|
||||
|---|---|---|---|---|---|---|---|---|---|---|
| Diameter (mm): 3 | Shank (mm): 6 | Radius: 0.3 | Flute Length (mm): 7 | Overall Length (mm): 54 | Reach (mm): 12 | Flutes: 4 |
In stock
|
£30.46
£25.38
|
|
|
| Diameter (mm): 3 | Shank (mm): 6 | Radius: 0.5 | Flute Length (mm): 7 | Overall Length (mm): 54 | Reach (mm): 12 | Flutes: 4 |
5 days*
|
£30.46
£25.38
|
|
|
| Diameter (mm): 3 | Shank (mm): 6 | Radius: 0.3 | Flute Length (mm): 7 | Overall Length (mm): 57 | Reach (mm): 17 | Flutes: 4 |
In stock
|
£30.46
£25.38
|
|
|
| Diameter (mm): 3 | Shank (mm): 6 | Radius: 0.5 | Flute Length (mm): 7 | Overall Length (mm): 57 | Reach (mm): 17 | Flutes: 4 |
5 days*
|
£30.46
£25.38
|
|
|
| Diameter (mm): 4 | Shank (mm): 6 | Radius: 0.3 | Flute Length (mm): 8 | Overall Length (mm): 57 | Reach (mm): 15 | Flutes: 4 |
In stock
|
£30.76
£25.63
|
|
|
| Diameter (mm): 4 | Shank (mm): 6 | Radius: 0.5 | Flute Length (mm): 8 | Overall Length (mm): 57 | Reach (mm): 15 | Flutes: 4 |
5 days*
|
£30.76
£25.63
|
|
|
| Diameter (mm): 4 | Shank (mm): 6 | Radius: 0.3 | Flute Length (mm): 8 | Overall Length (mm): 63 | Reach (mm): 22 | Flutes: 4 |
In stock
|
£30.76
£25.63
|
|
|
| Diameter (mm): 4 | Shank (mm): 6 | Radius: 0.5 | Flute Length (mm): 8 | Overall Length (mm): 63 | Reach (mm): 22 | Flutes: 4 |
5 days*
|
£30.76
£25.63
|
|
|
| Diameter (mm): 5 | Shank (mm): 6 | Radius: 0.3 | Flute Length (mm): 10 | Overall Length (mm): 57 | Reach (mm): 17 | Flutes: 4 |
5 days*
|
£31.07
£25.89
|
|
|
| Diameter (mm): 5 | Shank (mm): 6 | Radius: 0.5 | Flute Length (mm): 10 | Overall Length (mm): 57 | Reach (mm): 17 | Flutes: 4 |
5 days*
|
£31.07
£25.89
|
|
|
| Diameter (mm): 5 | Shank (mm): 6 | Radius: 0.3 | Flute Length (mm): 10 | Overall Length (mm): 67 | Reach (mm): 27 | Flutes: 4 |
5 days*
|
£31.07
£25.89
|
|
|
| Diameter (mm): 5 | Shank (mm): 6 | Radius: 0.5 | Flute Length (mm): 10 | Overall Length (mm): 67 | Reach (mm): 27 | Flutes: 4 |
In stock
|
£31.07
£25.89
|
|
|
| Diameter (mm): 6 | Shank (mm): 6 | Radius: 0.3 | Flute Length (mm): 10 | Overall Length (mm): 57 | Reach (mm): 15 | Flutes: 4 |
5 days*
|
£31.37
£26.14
|
|
|
| Diameter (mm): 6 | Shank (mm): 6 | Radius: 0.5 | Flute Length (mm): 10 | Overall Length (mm): 57 | Reach (mm): 15 | Flutes: 4 |
5 days*
|
£31.37
£26.14
|
|
|
| Diameter (mm): 6 | Shank (mm): 6 | Radius: 1 | Flute Length (mm): 10 | Overall Length (mm): 57 | Reach (mm): 15 | Flutes: 4 |
5 days*
|
£31.37
£26.14
|
|
|
| Diameter (mm): 6 | Shank (mm): 6 | Radius: 0.3 | Flute Length (mm): 10 | Overall Length (mm): 62 | Reach (mm): 20 | Flutes: 4 |
5 days*
|
£31.37
£26.14
|
|
|
| Diameter (mm): 6 | Shank (mm): 6 | Radius: 0.5 | Flute Length (mm): 10 | Overall Length (mm): 62 | Reach (mm): 20 | Flutes: 4 |
In stock
|
£31.37
£26.14
|
|
|
| Diameter (mm): 6 | Shank (mm): 6 | Radius: 1 | Flute Length (mm): 10 | Overall Length (mm): 62 | Reach (mm): 20 | Flutes: 4 |
5 days*
|
£31.37
£26.14
|
|
|
| Diameter (mm): 6 | Shank (mm): 6 | Radius: 0.3 | Flute Length (mm): 10 | Overall Length (mm): 74 | Reach (mm): 32 | Flutes: 4 |
In stock
|
£31.37
£26.14
|
|
|
| Diameter (mm): 6 | Shank (mm): 6 | Radius: 0.5 | Flute Length (mm): 10 | Overall Length (mm): 74 | Reach (mm): 32 | Flutes: 4 |
5 days*
|
£31.37
£26.14
|
|
|
| Diameter (mm): 6 | Shank (mm): 6 | Radius: 1 | Flute Length (mm): 10 | Overall Length (mm): 74 | Reach (mm): 32 | Flutes: 4 |
In stock
|
£31.37
£26.14
|
|
|
| Diameter (mm): 8 | Shank (mm): 8 | Radius: 0.5 | Flute Length (mm): 12 | Overall Length (mm): 63 | Reach (mm): 20 | Flutes: 4 |
5 days*
|
£39.22
£32.68
|
|
|
| Diameter (mm): 8 | Shank (mm): 8 | Radius: 1 | Flute Length (mm): 12 | Overall Length (mm): 63 | Reach (mm): 20 | Flutes: 4 |
5 days*
|
£39.22
£32.68
|
|
|
| Diameter (mm): 8 | Shank (mm): 8 | Radius: 0.5 | Flute Length (mm): 12 | Overall Length (mm): 73 | Reach (mm): 30 | Flutes: 4 |
In stock
|
£43.27
£36.06
|
|
|
| Diameter (mm): 8 | Shank (mm): 8 | Radius: 1 | Flute Length (mm): 12 | Overall Length (mm): 73 | Reach (mm): 30 | Flutes: 4 |
5 days*
|
£43.27
£36.06
|
|
|
| Diameter (mm): 8 | Shank (mm): 8 | Radius: 0.5 | Flute Length (mm): 12 | Overall Length (mm): 90 | Reach (mm): 46 | Flutes: 4 |
5 days*
|
£46.63
£38.86
|
|
|
| Diameter (mm): 10 | Shank (mm): 10 | Radius: 0.5 | Flute Length (mm): 14 | Overall Length (mm): 72 | Reach (mm): 25 | Flutes: 4 |
5 days*
|
£59.51
£49.59
|
|
|
| Diameter (mm): 10 | Shank (mm): 10 | Radius: 1 | Flute Length (mm): 14 | Overall Length (mm): 72 | Reach (mm): 25 | Flutes: 4 |
5 days*
|
£59.51
£49.59
|
|
|
| Diameter (mm): 10 | Shank (mm): 10 | Radius: 0.5 | Flute Length (mm): 14 | Overall Length (mm): 82 | Reach (mm): 35 | Flutes: 4 |
5 days*
|
£67.84
£56.53
|
|
|
| Diameter (mm): 10 | Shank (mm): 10 | Radius: 1 | Flute Length (mm): 14 | Overall Length (mm): 82 | Reach (mm): 35 | Flutes: 4 |
5 days*
|
£67.84
£56.53
|
|
|
| Diameter (mm): 10 | Shank (mm): 10 | Radius: 0.5 | Flute Length (mm): 14 | Overall Length (mm): 102 | Reach (mm): 55 | Flutes: 4 |
5 days*
|
£71.38
£59.48
|
|
|
| Diameter (mm): 10 | Shank (mm): 10 | Radius: 1 | Flute Length (mm): 14 | Overall Length (mm): 102 | Reach (mm): 55 | Flutes: 4 |
5 days*
|
£71.38
£59.48
|
|
|
| Diameter (mm): 12 | Shank (mm): 12 | Radius: 0.5 | Flute Length (mm): 16 | Overall Length (mm): 83 | Reach (mm): 30 | Flutes: 4 |
In stock
|
£82.66
£68.88
|
|
|
| Diameter (mm): 12 | Shank (mm): 12 | Radius: 1 | Flute Length (mm): 16 | Overall Length (mm): 83 | Reach (mm): 30 | Flutes: 4 |
5 days*
|
£82.66
£68.88
|
|
|
| Diameter (mm): 12 | Shank (mm): 12 | Radius: 2 | Flute Length (mm): 16 | Overall Length (mm): 83 | Reach (mm): 30 | Flutes: 4 |
5 days*
|
£82.66
£68.88
|
|
|
| Diameter (mm): 12 | Shank (mm): 12 | Radius: 0.5 | Flute Length (mm): 16 | Overall Length (mm): 93 | Reach (mm): 40 | Flutes: 4 |
5 days*
|
£86.69
£72.24
|
|
|
| Diameter (mm): 12 | Shank (mm): 12 | Radius: 1 | Flute Length (mm): 16 | Overall Length (mm): 93 | Reach (mm): 40 | Flutes: 4 |
5 days*
|
£86.69
£72.24
|
|
|
| Diameter (mm): 12 | Shank (mm): 12 | Radius: 2 | Flute Length (mm): 16 | Overall Length (mm): 93 | Reach (mm): 40 | Flutes: 4 |
5 days*
|
£90.16
£75.13
|
|
|
| Diameter (mm): 12 | Shank (mm): 12 | Radius: 0.5 | Flute Length (mm): 16 | Overall Length (mm): 117 | Reach (mm): 64 | Flutes: 4 |
5 days*
|
£110.83
£92.36
|
|
|
| Diameter (mm): 12 | Shank (mm): 12 | Radius: 1 | Flute Length (mm): 16 | Overall Length (mm): 117 | Reach (mm): 64 | Flutes: 4 |
5 days*
|
£110.83
£92.36
|
|
|
| Diameter (mm): 12 | Shank (mm): 12 | Radius: 2 | Flute Length (mm): 16 | Overall Length (mm): 117 | Reach (mm): 64 | Flutes: 4 |
5 days*
|
£110.83
£92.36
|
|
|
| Diameter (mm): 16 | Shank (mm): 16 | Radius: 1 | Flute Length (mm): 22 | Overall Length (mm): 92 | Reach (mm): 38 | Flutes: 4 |
In stock
|
£145.09
£120.91
|
|
|
| Diameter (mm): 16 | Shank (mm): 16 | Radius: 2 | Flute Length (mm): 22 | Overall Length (mm): 92 | Reach (mm): 38 | Flutes: 4 |
5 days*
|
£145.09
£120.91
|
|
|
| Diameter (mm): 16 | Shank (mm): 16 | Radius: 3 | Flute Length (mm): 22 | Overall Length (mm): 92 | Reach (mm): 38 | Flutes: 4 |
5 days*
|
£145.09
£120.91
|
|
|
| Diameter (mm): 16 | Shank (mm): 16 | Radius: 1 | Flute Length (mm): 22 | Overall Length (mm): 109 | Reach (mm): 55 | Flutes: 4 |
5 days*
|
£184.10
£153.42
|
|
|
| Diameter (mm): 16 | Shank (mm): 16 | Radius: 2 | Flute Length (mm): 22 | Overall Length (mm): 109 | Reach (mm): 55 | Flutes: 4 |
5 days*
|
£184.10
£153.42
|
|
|
| Diameter (mm): 16 | Shank (mm): 16 | Radius: 3 | Flute Length (mm): 22 | Overall Length (mm): 109 | Reach (mm): 55 | Flutes: 4 |
5 days*
|
£184.10
£153.42
|
|
|
| Diameter (mm): 16 | Shank (mm): 16 | Radius: 1 | Flute Length (mm): 22 | Overall Length (mm): 141 | Reach (mm): 87 | Flutes: 4 |
5 days*
|
£198.72
£165.60
|
|
|
| Diameter (mm): 16 | Shank (mm): 16 | Radius: 2 | Flute Length (mm): 22 | Overall Length (mm): 141 | Reach (mm): 87 | Flutes: 4 |
5 days*
|
£149.04
£124.20
|
|
|
| Diameter (mm): 16 | Shank (mm): 16 | Radius: 3 | Flute Length (mm): 22 | Overall Length (mm): 141 | Reach (mm): 87 | Flutes: 4 |
5 days*
|
£198.72
£165.60
|
|
|
| Diameter (mm): 20 | Shank (mm): 20 | Radius: 1 | Flute Length (mm): 26 | Overall Length (mm): 104 | Reach (mm): 50 | Flutes: 4 |
In stock
|
£255.84
£213.20
|
|
|
| Diameter (mm): 20 | Shank (mm): 20 | Radius: 2 | Flute Length (mm): 26 | Overall Length (mm): 104 | Reach (mm): 50 | Flutes: 4 |
5 days*
|
£191.88
£159.90
|
|
|
| Diameter (mm): 20 | Shank (mm): 20 | Radius: 3 | Flute Length (mm): 26 | Overall Length (mm): 104 | Reach (mm): 50 | Flutes: 4 |
5 days*
|
£191.88
£159.90
|
|
|
| Diameter (mm): 20 | Shank (mm): 20 | Radius: 1 | Flute Length (mm): 26 | Overall Length (mm): 124 | Reach (mm): 70 | Flutes: 4 |
5 days*
|
£325.91
£271.59
|
|
|
| Diameter (mm): 20 | Shank (mm): 20 | Radius: 2 | Flute Length (mm): 26 | Overall Length (mm): 124 | Reach (mm): 70 | Flutes: 4 |
5 days*
|
£244.43
£203.69
|
|
|
| Diameter (mm): 20 | Shank (mm): 20 | Radius: 3 | Flute Length (mm): 26 | Overall Length (mm): 124 | Reach (mm): 70 | Flutes: 4 |
5 days*
|
£325.91
£271.59
|
|
|
| Diameter (mm): 20 | Shank (mm): 20 | Radius: 1 | Flute Length (mm): 26 | Overall Length (mm): 164 | Reach (mm): 110 | Flutes: 4 |
5 days*
|
£378.24
£315.20
|
|
|
| Diameter (mm): 20 | Shank (mm): 20 | Radius: 2 | Flute Length (mm): 26 | Overall Length (mm): 164 | Reach (mm): 110 | Flutes: 4 |
5 days*
|
£283.68
£236.40
|
|
|
| Diameter (mm): 20 | Shank (mm): 20 | Radius: 3 | Flute Length (mm): 26 | Overall Length (mm): 164 | Reach (mm): 110 | Flutes: 4 |
5 days*
|
£378.24
£315.20
|
|
Product Information
Features & Benefits
GMF63 series CORNER RADIUS end mills are available from 3-20mm diameter with a Weldon shank. The neck of the cutter is reduced in diameter to prevent interference with the workpiece. The V7 plus range from YG-1 offer the highest metal removal rates and silent machining of steels, stainless steels, heat resistant super alloys such as inconel & cast iron. The special multiple helix design eliminates vibration when employing large cuts and high feed rates. The results are exceptional tool life, excellent surface finish and the shortest cycle times. For the best results use in a hydraulic chuck or high-performance tool holder with excellent clamping torque.
- Y1200 coated ultrafine micrograin carbide
- HPC (High performance cutting)
- Multiple helix geometries and unequal flute spacing enable higher feed rates and larger cut��depths
- Helix & unequal flute spacing reduces vibration
- High heat resistance of Y1200 coating ensures exceptional tool life in stainless steel, titanium and HRSA machining
Specification
| Category | Milling |
|---|---|
| Sub Category | Milling Cutters |
| Sub Category 2 | V7 Plus Milling Cutters |
| Substrate | Carbide |
| Surface Treatment | Coated (PVD/CVD) |
| End Profile | Corner Radius |
| Flute Type | Long Neck |
| Shank Type | Weldon |
| Applicable Materials | Steel, Stainless Steel, Cast Iron, Exotics |
| Helix Profile | Variable Multiple Helix |
| Performance | 5 |
| Coating Description | Y1200 Coated |
| Substrate Description | Ultrafine Micrograin Carbide |
| Helix Angle | Multiple Helix |
| Brand Range | V7 Plus |
| Brand | YG-1 |
