i-X Mill Steel Shank Taper Neck Holder for Ball Nose Inserts - ZBT Series (YG-1)

i-X Mill Steel Shank Taper Neck Holder for Ball Nose Inserts - ZBT Series (YG-1)

The YG-1 ZBT series i-X Mill copy milling holder has a steel shank, a tapered neck and takes both ball nose and corner radius inserts from 8mm to 33mm. This premium alloy steel holder has excellent st...

Premium Alloy Steel shank (low cost, excellent strength, precise h6 tolerance and is nickel plated to prevent corrosion).
Ideal for Slotting, Ramping, Helical Cutting and Copy Milling applications.
5 insert geometries available for general, pre-hardened steel, high hardened steel, graphite and aluminium milling.
Tapered neck design for longer reach applications.
For insert widths between 12mm and 33mm.
Suitable for use with both ball nose (XMB/XMM series) and corner radius (XMR/XMF series) inserts.
High feed inserts for high metal removal rates.
Holders for high feed/corner radius milling ensures highest accuracy & performance.
High accuracy strong clamping screw & high precision insert location.
Ball radius tolerance of 0.01mm, set up accuracy of 0.02mm.
220° full ball nose insert for 5 axis machining.

Size

Overall Length (mm)	90 - 250
Shank (mm)	12 - 32

From £86.90 £72.42

View Products

i-X Mill Steel Shank Holder for Ball Nose Inserts - ZBS Series (YG-1)

i-X Mill Steel Shank Holder for Ball Nose Inserts - ZBS Series (YG-1)

The YG-1 ZBS series i-X Mill copy milling holder has a steel shank and takes both ball nose and corner radius inserts from 12mm to 33mm. This premium alloy steel holder has excellent strength, precise...

Premium Alloy Steel shank (low cost, excellent strength, precise h6 tolerance and is nickel plated to prevent corrosion).
Ideal for Slotting, Ramping, Helical Cutting and Copy Milling applications.
5 insert geometries available for general, pre-hardened steel, high hardened steel, graphite and aluminium milling.
Straight neck design.
For insert widths between 12mm and 33mm.
Suitable for use with both ball nose (XMB/XMM series) and corner radius (XMR/XMF series) inserts.
High feed inserts for high metal removal rates.
Holders for high feed/corner radius milling ensures highest accuracy & performance.
High accuracy strong clamping screw & high precision insert location.
Ball radius tolerance of 0.01mm, set up accuracy of 0.02mm.
220° full ball nose insert for 5 axis machining.

Size

Overall Length (mm)	90 - 250
Shank (mm)	12 - 32

From £82.86 £69.05

View Products

i-X Mill Steel Shank Holder for Corner Radius Inserts - ZRS Series (YG-1)

i-X Mill Steel Shank Holder for Corner Radius Inserts - ZRS Series (YG-1)

The YG-1 ZRS series i-X Mill copy milling holder has a steel shank and takes corner radius inserts from 12mm to 32mm. This premium alloy steel holder has excellent strength, precise h6 tolerance and i...

Premium Alloy Steel shank (low cost, excellent strength, precise h6 tolerance and is nickel plated to prevent corrosion).
Ideal for Slotting, Ramping, Helical Cutting and Copy Milling applications.
5 insert geometries available for general, pre-hardened steel, high hardened steel, graphite and aluminium milling.
Straight neck design.
For insert widths between 12mm and 32mm.
Suitable for use with corner radius (XMR/XMF series) inserts.
High feed inserts for high metal removal rates.
Holders for high feed/corner radius milling ensures highest accuracy & performance.
High accuracy strong clamping screw & high precision insert location.

Size

Diameter (mm)	12 - 32
Overall Length (mm)	110 - 300
Shank (mm)	12 - 32

From £82.86 £69.05

View Products

i-X Mill Steel Shank Taper Neck Holder for Corner Radius Inserts - ZRT Series (YG-1)

i-X Mill Steel Shank Taper Neck Holder for Corner Radius Inserts - ZRT Series (YG-1)

The YG-1 ZRT series i-X Mill copy milling holder has a steel shank, a tapered neck and takes corner radius inserts from 8mm to 12mm. This premium alloy steel holder has excellent strength, precise h6 ...

Premium Alloy Steel shank (low cost, excellent strength, precise h6 tolerance and is nickel plated to prevent corrosion).
Ideal for Slotting, Ramping, Helical Cutting and Copy Milling applications.
5 insert geometries available for general, pre-hardened steel, high hardened steel, graphite and aluminium milling.
Tapered neck design for longer reach applications.
For insert widths between 12mm and 32mm.
Suitable for use with corner radius (XMR/XMF series) inserts.
High feed inserts for high metal removal rates.
Holders for high feed/corner radius milling ensures highest accuracy & performance.
High accuracy strong clamping screw & high precision insert location.

Size

Diameter (mm)	8 - 12
Overall Length (mm)	100 - 350
Shank (mm)	12 - 32

From £86.90 £72.42

View Products

i-X Mill Carbide Shank Holder for Ball Nose Inserts - ZBC Series (YG-1)

i-X Mill Carbide Shank Holder for Ball Nose Inserts - ZBC Series (YG-1)

The YG-1 ZBC series i-X Mill copy milling holder has a carbide shank and takes both ball nose and corner radius inserts from 8mm to 33mm. This carbide holder give more rigidity, better surface finish ...

Premium Carbide shank (more rigidity, better surface finish even in longer length applications, longer tool life and can also be used in shrink fit chucks).
Ideal for Slotting, Ramping, Helical Cutting and Copy Milling applications.
5 insert geometries available for general, pre-hardened steel, high hardened steel, graphite and aluminium milling.
Straight neck design.
As rigid as solid carbide end mills - for high finish machining with less vibration.
For insert widths between 12mm and 33mm.
Exceptional surface finish, even in long reach applications with carbide shank holders.
Suitable for use with both ball nose (XMB/XMM series) and corner radius (XMR/XMF series) inserts.
High feed inserts for high metal removal rates.
Holders for high feed/corner radius milling ensures highest accuracy & performance.
High accuracy strong clamping screw & high precision insert location.
Ball radius tolerance of 0.01mm, set up accuracy of 0.02mm.
220° full ball nose insert for 5 axis machining.

Size

Overall Length (mm)	80 - 300
Shank (mm)	8 - 25

From £103.92 £86.60

View Products
