High Performance Universal Metric Fine Machine Taps | Cutwel -Thread Cutting Tool Specialist

Metric Fine Powder Metal Spiral Flute Universal Plus Machine Tap - TRE04 Series (YG-1)

Metric Fine Powder Metal Spiral Flute Universal Plus Machine Tap - TRE04 Series (YG-1)

The YG-1 TRE04 Metric Fine Powder Metal Universal Plus Machine Taps are part of the Prime Tap range for high performance tapping on: Steel, Pre-Hardened Steel, Stainless Steel, Cast Iron, Titanium, Ni...

Metric Fine Universal Plus Machine Tap
Powder Metal Substrate for increased tool life
For High Performance Purpose Tapping on Steel, Pre-Hardened Steel, Stainless Steel, Cast Iron, Titanium, Nickel, Copper, Copper Alloy & Aluminium
Patented design to prevent over feeding and premature tap failure
Bright finish prevents swarf sticking to the tap flutes
Spiral Flute geometry for Blind Holes

Size

Overall Length (mm)	63 - 150
Flute Length (mm)	5 - 28
Shank (mm)	2.8 - 22

From £22.20 £18.50

View Products

Metric Fine Powder Metal Spiral Flute Universal Plus Prime-X Machine Tap - (YG-1)

Prime-X YG-1 Premium HSS-PM Machine Taps have a unique X-coating and a tough chip resistant cutting edge which provide ultra long tool life, high heat resistance and high performance tapping on a wide...

Metric Fine Prime-X Universal Plus Machine Tap
New YG-1 X-coating provides high heat and wear resistance
Premium Powder Metal Substrate with tough-chipping resistant cutting edge
For High Performance Purpose Tapping on Steel, Stainless Steel, Cast Iron & Non-Ferrous
Special thread structure for the reduction of torque, wear and risk of overfeeding
Unrestricted chip flow as a result of the optimised combination of substrate, coating and geometry
Spiral Flute geometry for Blind Holes

Size

Overall Length (mm)	63 - 140
Flute Length (mm)	5.6 - 20
Shank (mm)	2.8 - 18

From £26.92 £22.43

View Products

Metric Fine Powder Metal Spiral Point Universal Plus Prime-X Machine Tap - (YG-1)

Prime-X YG-1 Premium HSS-PM Machine Taps have a unique X-coating and a tough chip resistant cutting edge which provide ultra long tool life, high heat resistance and high performance tapping on a wide...

Metric Fine Prime-X Universal Plus Machine Tap
New YG-1 X-coating provides high heat and wear resistance
Premium Powder Metal Substrate with tough-chipping resistant cutting edge
For High Performance Purpose Tapping on Steel, Stainless Steel, Cast Iron & Non-Ferrous
Special thread structure for the reduction of torque, wear and risk of overfeeding
Unrestricted chip flow as a result of the optimised combination of substrate, coating and geometry
Spiral point geometry for Through Holes

Size

Overall Length (mm)	63 - 140
Flute Length (mm)	10 - 27
Shank (mm)	2.8 - 18

From £26.92 £22.43

View Products

Metric Fine Powder Metal Spiral Point Universal Plus Machine Tap - TRJ04 Series (YG-1)

Metric Fine Powder Metal Spiral Point Universal Plus Machine Tap - TRJ04 Series (YG-1)

The YG-1 TRJ04 Metric Fine Powder Metal Universal Plus Machine Taps are part of the Prime Tap range for high performance tapping on: Steel, Pre-Hardened Steel, Stainless Steel, Cast Iron, Titanium, Ni...

Metric Fine Universal Plus Machine Tap
Powder Metal Substrate for increased tool life
For High Performance Purpose Tapping on Steel, Pre-Hardened Steel, Stainless Steel, Cast Iron, Titanium, Nickel, Copper, Copper Alloy & Aluminium
Patented design to prevent over feeding and premature tap failure
Bright finish prevents swarf sticking to the tap flutes
Spiral point geometry for through holes

Size

Overall Length (mm)	63 - 150
Flute Length (mm)	10 - 30
Shank (mm)	2.8 - 22

From £22.20 £18.50

View Products
