QCRL 60 / Z170 Quick Change Modular Lathe Collet Chuck - Q-CRL Series (Klamp)
QCRL 60 / Z170 Quick Change Modular Lathe Collet Chuck - Q-CRL Series (Klamp)
Related Products
| Image | Code | Stock | Price (Ex VATInc. VAT) |
|---|
Product Information
Features & Benefits
- As per the direct mount system except with interchangeable adaptors enables the collet chuck to be moved from one machine spindle nose to another.
- Cost-effective as only additional adaptors and connectors are required.
- The need for adjustment is minimal, meaning less machine downtime.
- Made in the United Kingdom.
Specification
| D | 60 |
|---|---|
| A | 118 |
| B | 31.5 |
| Weight | 28.3 |
| Category | Workholding |
| Sub Category | Workholding Collets & Chucks |
| L | 220 |
| G | 14 (max) / 7 (min) |
| Collet Size | D185E 3-60mm (0.5mm inc.) / D677 / M677 4-60mm (2mm inc.) / DRFC677 19-65mm (2mm inc.) |
| E | M75x1.5 |
| Max RPM | 6300 |
| Clamping Force | 60kN |
| F | 82 |
| A1 | 171 |
| Mount | Z170 |
| Max Input Force | 30kN |
| Sleeve Stroke | 7 |
